As a GPU Poor individual with an Apple M1 MacBook, I had no way to run CUDA code locally as I go through the Programming Massively Parallel Processors textbook. As a result, I found myself looking for ways to run CUDA code on the cloud (someone else's computer) for free. LeetGPU looked promising, but I am too lazy to try a new platform and decided to stick with the good ol' Google Colab. For the uninitiated, Colab is a way to run Jupyter notebooks in the cloud with a free tier that lets you access GPUs (and TPUs) for a limited time.

A quick google search returned a few tutorials on this, and a handy Python package nvcc4jupyter that would allow me to write CUDA directly into Colab code cells and compile them easily with some magic commands. How convenient! I ran their Hello World example. However, this printed no output. Suspicious!

I tried to go one step further, and wrote a simple CUDA kernel for elementwise vector addition with some error handling to understand what was going on. Trying to run this with nvcc4jupyter's %cuda magic command gave me the following response: CUDA error in /tmp/tmpjnowjf_2/b1cdcef3-2dc4-4ef4-94e4-f2cd3aae3655/single_file.cu at line 66: the provided PTX was compiled with an unsupported toolchain. Perhaps, there is no free lunch when it comes to accessing GPUs on the cloud as well!

Identifying the Problem

Let me actually take a step back, and walk you through my process of trying to get CUDA working on Colab, and how I identified the underlying problem. This might be trivial for someone familiar with CUDA and NVCC (NVIDIA CUDA Compiler), but will probably be insightful for machine learning practitioners who have only interacted with CUDA through high-level libraries.

Attempt #1: Using nvcc4jupyter

The top result from Google when searching for 'Run cuda on colab' is a discussion on NVIDIA developer forums from 2022, which links to this StackOverflow discussion which uses nvcc4jupyter and is very similar to what I just did. No luck here!

The second result is this Medium article from 2024 called Running CUDA on Google Colab for free which again refers to nvcc4jupyter, and to add insult to injury the article shows that the nvcc4jupyter hello world example runs successfully on Colab. Hmmm, so clearly something has changed with either the package or the Google Colab environment since then.

First, I checked what GPU and CUDA version I was working with:

!nvidia-smi

Which showed I had a Tesla T4 GPU with CUDA 12.4:

+-------------------------------------------------------------------------------------+
| NVIDIA-SMI 550.54.15          Driver Version: 550.54.15      CUDA Version: 12.4     |
|-------------------------------------+------------------------+----------------------+
| GPU  Name             Persistence-M | Bus-Id          Disp.A | Volatile Uncorr. ECC |
| Fan  Temp   Perf      Pwr:Usage/Cap |           Memory-Usage | GPU-Util  Compute M. |
|                                     |                        |               MIG M. |
|=====================================+========================+======================|
|   0  Tesla T4                   Off |   00000000:00:04.0 Off |                    0 |
| N/A   35C    P8          9W /   70W |       0MiB /  15360MiB |      0%      Default |
|                                     |                        |                  N/A |
+-------------------------------------+------------------------+----------------------+

Next I confirmed the nvcc compiler version:

!nvcc --version

nvcc: NVIDIA (R) Cuda compiler driver
Copyright (c) 2005-2024 NVIDIA Corporation
Built on Thu_Jun__6_02:18:23_PDT_2024
Cuda compilation tools, release 12.5, V12.5.82
Build cuda_12.5.r12.5/compiler.34385749_0

On a more serious note, this was a helpful lead - the CUDA toolkit (12.5) is newer than the driver version (12.4). This version mismatch might explain some of the issues I was facing.

At this point, I looked up Issues on the nvcc4jupyter Github repository and lo-and-behold:

Bingo! Someone else also encountered the same problem as I, and in fact there was already a workaround in the comments! A comment from Github user mohamedsamirx had linked a detailed Colab notebook on YOLOv12 TensorRT Inference Using CPP And CUDA. They had diagnosed the same exact issue, and in fact the workaround involved them explicitly removing CUDA-12.5 and symlinking the /usr/local/cuda folder to /usr/local/cuda-12.4.

I checked the CUDA Compatibility Guide and while it said:

it also included a caveat:

So it seems to me (as a CUDA novice) that if you compiled your CUDA code with the right flags, and/or already have the compiled binary available, it should be able to run on an older driver of the same CUDA release family for CUDA 12.x or CUDA 11.x. This was confirmed when I read about the CUDA compilation process , which I discussed in the next section. But for our case, where we want to write and compile CUDA code ourself, it is important to match the toolkit version with the driver version.

As an aside, I also found out that Google Colab has an active Github organization where they detail CUDA version upgrades to their Colab VM via label=feature issues. It seems like the CUDA-12.5 upgrade happened just a few days before this blog was written! Oh, and a bunch of folks are ranting about how the upate broke stuff for them in the CUDA 12.5 upgrade issue comments ;)

Attempt #2: Using nvcc4jupyter with compiler flags

Now, as I was trying to pinpoint the issue with nvcc4jupyter, I learned a way that I could get away without downgrading my CUDA version for the free tier T4 GPU on Colab. Understanding why requires a slight detour into NVIDIA's GPU compute capabilities and how nvcc can control the machine code generated.

When NVCC compiles CUDA code, the representations follow this sequence:

• Source code → PTX (intermediate representation) → Cubin (binary)

where PTX is architecture-independent but CUDA version-specific, while Cubin is specific to a particular CUDA Compute Capability

According to NVIDIA (compute capability) identifies the features supported by the GPU hardware and is used by applications at runtime to determine which hardware features and/or instructions are available on the present GPU. Since GPUs have different hardware architectures with generations, the machine code compiled to run on them varies in order to best utilize the available capabilities.

Now, the Tesla T4 GPU on Colab's free tier is an older GPU, launched over seven years ago in 2018. It has a Compute Capability (also called SM version) of 7.5 (abbreviated as sm_75). The compute capability does not translate 1-1 to the CUDA toolkit versions, but I found this somewhat dated but neat table from StackOverflow which shows the relation between them:

So, while there is indeed an issue with the NVIDIA Toolkit and Driver version mismatch on Colab, you probably don't need all the compute capabilities that CUDA-12.4 supports to run your code on the T4 since it has a compute capability of 7.5.

The nvcc compiler offers several command options in order to control the compilation and machine code generation process. Of particular interest to our case is the -arch or --gpu-architecture flag which specifies the architecture of the GPU for which the code is being compiled.

nvcc4jupyter allows you to pass compiler flags to the underlying nvcc compiler using the -c option. So, I tried to pass the architecture flag to nvcc4jupyter:

%%cuda -c="-arch=sm_75"
#include <iostream>
#include <cuda_runtime.h>
// ... rest of the code ...

But this resulted in a parser error:

usage: colab_kernel_launcher.py [-h] [-t] [-p] [-l PROFILER] [-a PROFILER_ARGS] [-c COMPILER_ARGS]
colab_kernel_launcher.py: error: argument -c/--compiler-args: expected one argument

I experimented with a few different spacing formats, such as

%%cuda -c="-arch sm_75"

but I kept running into the same error. It seemed like nvcc4jupyter had issues parsing and passing compiler arguments to the underlying nvcc compiler. A second visit to the nvcc4jupyter issues page confirmed my suspicions:

As I read through the issue comments and then later through argument parsing code in nvcc4jupyter, I found out that there is a hacky workaround to solving this issue (mentioned below). But the argument parser in nvcc4jupyter is not quite comprehensive enough in the way it parses compiler arguments like -l (for linking libraries) or -arch (for specifying the architecture), and would require a patch for a proper solution to the underlying issue.

%%cuda -c "-I /does/not/exist -arch sm_75"

Actually, going through the package code made me realize that the package is a very lightweight wrapper to making nvcc calls, which led me on to my next attempt.

Attempt #3: Using nvcc directly

Since nvcc4jupyter wasn't cooperating in specifying nvcc command options, I decided to try compiling and running my CUDA code directly using the nvcc compiler since it comes pre-installed with Colab. One of the really neat aspects of jupyter notebooks is the ability to run bash commands directly using the ! prefix. And since we have access to the command line, we can (among other things) write our CUDA code to a file, compile it using nvcc, and run the resulting executable. So, I started by writing out my vector addition code to a file:

%%writefile vector_add.cu
#include <iostream>
#include <cuda_runtime.h>
// ... rest of the code ...

First, I tried compiling without specifying any architecture command options, just as a sanity check to verify that the error I saw with nvcc4jupyter magic commands was replicated in calling nvcc directly:

!nvcc vector_add.cu -o vector_add

When I ran the executable, I encountered the same PTX toolchain error as in Attempt #1. Time to try compiling with the architecture flag for the T4 GPU in Colab, and then running the binary:

!nvcc -arch=sm_75 vector_add.cu -o vector_add
!./vector_add

Finally, success! I got the expected output:

Input arrays:
A: 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
B: 0 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30
Launching kernel with gridSize=1, blockSize=256
Result array C: 0 3 6 9 12 15 18 21 24 27 30 33 36 39 42 45
Vector addition completed successfully!

Moving Forward

For now, I'm sticking with the direct nvcc compilation approach. The ability of jupyter notebooks to run bash commands really shines here, and while calling nvcc directly is a bit less convenient than using magic commands, it's reliable and gets the job done.

tl;dr

%%writefile your_code.cu
// Your CUDA code here

!nvcc -arch=sm_75 your_code.cu -o your_executable
!./your_executable

Thanks for reading, and happy coding!
